Features
- Enable you to track your vehicle in real time and give you peace of mind.
- Built-in GSM/GPS antenna; Support Google map link, no need of platform registration.
- Offer accurate and precision real-time tracking location data.
- Location inquiry by SMS / GPRS (class 12).
- GPS tracked by time interval via GPRS (10 - 18000s).
- Real-time location tracking via SMS.
- LED indicators display current working status.
- Compact and light, discrete or open installation.
- Password is required to make or change any setup to protect your property.
- Real time positioning and accurate positioning: Real-time tracking, automatic location information display (supports Android / IOS, Web / WAP), free real-time tracking, GPS / A GPS / LBS- up to 5 meters.
- Geo-Fence: If you set a geo-fence so that the device limits movement within a district, the device sends a message to the authorized number if it violates the district.
- Chronological memory: Within six months you can review and play back the path of the Web Monitor Center device. We know the position of your beloved child or elderly parent. You can set a security zone for your device to limit movement within a district. If you worry about their security, the tracker sends a message to the authorized number if it crosses the district.
- Overspeed alarm and motion alarm: When the vehicle is out of the set speed, the GPS tracker sends the warning message to the phone. Remember to drive safely. Move alarm (only works when you get the GPS signal, the circumference is a circle, radius 200 metres).
- Widely used: Built-in switching power supply, 9-36V input voltage, suitable for all cars, plug and work.
Specifications
| GPS Bands | GSM 850 / 900 / 1800 / 1900MHz |
| GPRS | Class 12 |
| GPS Sensitivity | -159dBm |
| Acquisition Sensitivity | -144dBm |
| Position Accuracy | 10m |
| TTFF | 38s (Cold Start), 32s (Warm Start), 2s (Hot Start) |
| GSM / GPS Antenna | Built-in |
| LED Indicator | Green - GSM, Blue - GPS, Red - Power |
| Data Transmission | TCP, SMS |
| Movement Detection | Movement Alarm Based on Built-in 3D Motion Sensor |
| Mileage Report | Tracked by Time / Distance Interval |
| Input | DC 9 - 36V (Plug and Use) |
| Working Temperature | -30~70℃ |
| Humidity | 20%~80% RH |
| Wire Length | 63" / 1.6m approx. |
| Material | Plastic |
| Color | Black |
| Dimensions | (3.54 x 1.77 x 0.53)" / (9 x 4.5 x 1.35)cm (L x W x H) |
| Weight | 1.55oz / 44g |
Package Includes
- 1 x GPS Tracker
- 1 x Wiring
- 1 x Retail Box
- 1 x English Manual
